Product Description:
The LED spherical display screen is equipped with a brightness of 1200CD, ensuring that your content is always visible and eye-catching. This makes it perfect for use in dimly lit environments like bars and clubs, where visibility is key.
Whether you're looking to advertise your products, display information, or simply entertain your guests, this irregular LED display screen is the perfect tool for the job. With its high refresh rate of 3840High Brush, you can be sure that your content will always be smooth and seamless, even when displaying fast-moving images.
So if you're looking for a reliable and high-quality indoor LED display screen for your bar or other indoor venue, look no further than our LED circular cake screen. With its stunning visual quality and easy installation, it's the perfect addition to any indoor space.
List of parameters
Module technical parameters:
| 01 |
Pixel spacing |
1.667mm |
07 |
Pixel density |
360000(Dots/㎡) |
| 02 |
Module size |
320mm×160mm×15mm |
08 |
Lamp packaging |
1212 |
| 03 |
Resolution |
192×96=18432(Dots) |
09 |
Structural features |
Lamp drive in one |
| 04 |
Scanning mode |
48S |
10 |
Input voltage |
4.2V±0.1V |
| 05 |
Drive IC |
6363/16380 |
11 |
Maximum current |
5A |
| 06 |
Pixel composition |
1R1G1B |
12 |
Module weight |
0.18Kg±0.01Kg |
Technical parameters of screen body:
| 01 |
Optimal sight distance |
1m～25m |
09 |
Average power consumption |
≤100W～300W/㎡ |
| 02 |
Horizontal viewing angle |
≥140 ° |
10 |
Maximum power consumption |
≤500W/㎡ |
| 03 |
Vertical viewing angle |
≥130 ° |
11 |
Refresh frequency |
≥3840Hz |
| 04 |
White balance brightness |
≥600CD/㎡ |
12 |
Frame change frequency |
≥60Hz |
| 05 |
Gray scale |
Class 16384 |
13 |
Operating voltage |
220V±15% |
| 06 |
Brightness adjustment |
Class 256 Manual/Auto |
14 |
Storage temperature |
-30℃~+60℃ |
| 07 |
Display color |
4,398 billion species |
15 |
Operating temperature |
-20℃~+50℃ |
| 08 |
Use environment |
Indoor |
16 |
Relative humidity |
10%～95% |
Technical parameters of the box:
| 01 |
Specification of the box |
640mm×480mm×80mm |
04 |
Box area |
0.3072 ㎡ |
| 02 |
Box resolution |
384×288=110592(Dots) |
05 |
Maximum power consumption |
≤178W/㎡ |
| 03 |
Box weight |
6.0Kg±0.05Kg |
06 |
Average power consumption |
≤59W/㎡ |
Features:
- Product Name: Indoor LED Display Screen
- Installation: Wall Mounted
- Led Lamp: Kinglight
- Refresh: 3840 High Brush
- Usage environment: Bar
- Brightness: 1200CD
- Right angle display screen
- Tree shaped LED display screen
Technical Parameters:
| Install |
Wall Mounted |
| LED Lamp |
Kinglight |
| Refresh |
3840High Brush |
| Usage Environment |
Bar |
| Brightness |
1200CD |
| Usage |
Indoor |
Applications:
This product is perfect for displaying promotional content, advertisements, and other important information in bars. The bright and clear display ensures that the content is easily visible even in dimly lit environments. The irregular LED display screen design adds a touch of modernity and sophistication to the bar environment, making it more attractive to customers.
Additionally, the kinglight P1.667 Indoor LED Display Screen is an excellent choice for displaying information in shopping malls. The clear and bright display ensures that shoppers can easily see promotional content and advertisements, which can help increase sales. The LED mirror display screen design also adds to the visual appeal of the display, making it more attractive to shoppers.
The kinglight P1.667 Indoor LED Display Screen is also an excellent choice for use in exhibition halls. The bright and clear display ensures that the content is easily visible from a distance, making it perfect for displaying important information and promotional content. The irregular LED display screen design adds a touch of modernity and sophistication to the exhibition hall environment, making it more attractive to visitors.
Installing the kinglight P1.667 Indoor LED Display Screen is quick and easy. The screen can be wall mounted, making it easy to install in a variety of indoor settings. The screen is also FCC and CE certified, ensuring that it meets high-quality standards. The minimum order quantity is only one, and delivery time is only 20 days. Payment terms are T/T, making it easy to purchase the product. With a refresh rate of 3840High Brush and LED lamps made by kinglight, the P1.667 Indoor LED Display Screen is a high-quality product that is sure to meet your needs.
Product description
● 1, gray contrast enhancement, so that the blurred picture becomes clearer, with the adjustment technology, very expressive color.HD restore to the point, improve the phenomenon of stutter and smear caused by the inability to restore to the point.
● 2. High contrast, consistent white balance, uniform display color, high picture definition, and enhanced image color.The phenomenon that the tone of the whole picture deviates from the primary color is improved, the picture faithfully displays the color of the material, and the visual effect is enhanced.Ultra-high refresh rate, smooth video, effectively avoid the appearance of scan lines.
● 3. The LED lamp adopts the 1212 black lamp packaged by the high-end chip of the world-renowned manufacturer.And that service life and the display quality of the display screen are fully ensure.
● 4. The effect of indoor full-color display screen is clearer and more delicate, and the resolution can reach more than 1080P;Realize high refresh rate, high gray scale and high lamp utilization rate; no residual image, anti-caterpillar, low power consumption and other functions.
● 5. The indoor full-color display screen is mainly composed of a red LED chip, a green LED chip and a blue LED chip packaged into an image.A matrix is formed after the pixel points are formed, and then the matrix is fixed on a plastic sleeve.
● 6. The indoor full-color display screen contains a driver chip and an input buffer chip.Connect to the LED display control system to display video, images, text messages, etc.
● 7. PCB board adopts multi-layer circuit design to ensure uniform current distribution and good heat dissipation of the lamp board.Prevent the appearance of color blocks under the condition of low gray scale and enhance the ability of anti-electromagnetic interference.
● 8. High-quality 1U gold-plated connectors are used, and there is no flat cable connection in the box, which is stable and reliable.
● 9. Dedicated 16 BIT high gray scale and high refresh drive constant current IC is used for drive and control, with special blanking circuit to protect LED.Prevent surge leakage.
● 10. The system controls and drives the driver chips of red, green and blue LEDs, which can form 4398 billion color transformations.
● 11. Unit boards and boxes can be spliced in horizontal and vertical directions to form display screens of different sizes.
● 12. Convenient and quick installation and disassembly, saving more cost.
Customization:
Support and Services:
Our Indoor LED Display Screen product comes with comprehensive technical support and services to ensure smooth operation and maximum performance. Our team of experts is available to assist with any issues or inquiries that may arise throughout the product's lifespan.
We offer installation and maintenance services to help set up the display screen and keep it running at optimal levels. Additionally, we provide training to ensure that users are able to operate the system with ease and efficiency.
Our technical support also includes troubleshooting and repair services in the event that any problems occur. We strive to provide timely and effective solutions to minimize any potential downtime and ensure that the display screen is back up and running as quickly as possible.
Overall, our Indoor LED Display Screen product is backed by a strong commitment to customer satisfaction and support. We are dedicated to providing the highest level of service and assistance to ensure that our customers get the most out of their investment.
