Product Description:
The control system for this LED screen is powered by Novastar, ensuring smooth and efficient operation. The panel size measures 960MM*960MM, making it large enough to catch the attention of passersby without being too overwhelming. The cabinet material is made of die-casting aluminum, providing durability and stability for outdoor use.
The Outdoor LED Display Screen comes with a reliable power supply from Meanwell, ensuring a steady source of power for uninterrupted use. The production time for this product is approximately 25 days, allowing for a timely delivery to meet your marketing needs.
Whether you're looking to showcase your products, services, or events, the Outdoor LED Display Screen is the perfect backdrop LED screen to make a lasting impression on your audience. With its high-quality display and reliable performance, this LED panel for advertising is an investment that will pay off for years to come.
Features:
- Product Name: Outdoor LED Display Screen
- Specification: Video Wall
- Module Size: 320mm*160mm
- Control System: Novastar
- Panel Size: 960MM*960MM
- Production Time: About 25 Days
- Compatible with backdrop led screen
- High resolution p6 led display
- Durable p10 led outdoor display
Module parameters
| 01 |
Module size |
320mm*160mm |
| 02 |
Pixel spacing |
10mm |
| 03 |
Scanning mode |
4S |
| 04 |
Module pixel point |
32 * 16 = 512 points |
| 05 |
Drive IC |
16208 |
| 06 |
Lamp bead model |
3535/2727 |
| 07 |
Physical density |
10,000 points/㎡ |
| 08 |
Pixel point composition |
1R1G1B |
| 09 |
Color |
R,G,B |
| 10 |
Brightness |
≥3800CD/㎡ |
| 11 |
Refresh frequency |
≥1920HZ |
| 12 |
Frame change frequency |
≥60Hz |
| 13 |
Display color |
256 * 256 * 256 = 16777216 color |
| 14 |
Optimal sight distance |
10～100M |
| 15 |
Operating temperature |
-25℃~+55℃ |
| 16 |
Relative humidity |
10%～95% |
| 17 |
Average power consumption |
200 ~ 300 W/㎡ (depending on the video source played) |
| 18 |
Maximum power consumption |
800W/㎡ |
| 19 |
Operating voltage |
220V±10％ ,50/60Hz |
| 20 |
Switching power supply load |
5V/40A,5V/30A |
| 21 |
Screen life |
≥ 100000 hours |
| 22 |
Quality and safety standards |
CE,CCC,ISO9001:2008,ROHS |
Technical Parameters:
| Technical Parameter |
Description |
| Product Name |
p5 outdoor led display, p6 led display, p10 led outdoor display |
| Power Supply |
Meanwell |
| Production Time |
About 25 Days |
| Specification |
Video Wall |
| Led Type |
SMD 1921/ 2727/3535 |
| Display Function |
Video |
| CPU |
Pentium4 Or Above |
| Module Size |
250mmx250mm |
| LED Lamp |
SMD1921 |
| Cabinet Material |
Die-casting Aluminum |
| LED Chip |
3 In 1 Smd |
Applications:
1. Outdoor Events: The P4 outdoor LED screen can be used in outdoor events such as concerts, festivals, and sports events. The high brightness and clarity of the screen make it ideal for displaying live feeds, replays, and advertisements.
2. Stadiums: The P6 LED display is perfect for use in stadiums as it can display high-quality graphics and videos to large crowds. It can be used for displaying match scores, advertisements, and other important information.
3. Public Spaces: The P10 outdoor LED screen can be used in public spaces such as parks, shopping malls, and airports. It can be used for displaying information, advertisements, and other messages to a large number of people.
4. Digital Signage: The P6 LED display can be used for digital signage in retail stores, hotels, and restaurants. It can be used for displaying product information, promotions, and other content to customers.
5. Transportation: The P10 outdoor LED screen can be used for transportation purposes such as displaying arrival and departure times, delays, and other important information at bus and train stations.
With a production time of about 25 days, the kinglight Outdoor LED Display Screen is a reliable and efficient product. It is made using high-quality materials and comes with a Meanwell power supply, Pentium4 CPU or above, and 3 in 1 SMD LED chips. The module size of 320mm*160mm makes it easy to install and maintain.
Customization:
Support and Services:
The product technical support and services for our Outdoor LED Display Screen include:
- Installation support and guidance
- On-site technical support if required
- 24/7 remote technical assistance
- Training and technical documentation
- Regular software updates and maintenance
Our team of experts is dedicated to ensuring that our customers receive the highest level of technical support and services for their Outdoor LED Display Screen.
